Automatic flap barrier

Functional characteristics:

    • With zero self-test function, to facilitate the maintenance and use of users;
    • Illegal entry with alarm function;
    • Erosion prevention function, in the absence of the received gate signal, the telescopic baffle (ARM) automatic lock;
    • Infrared/mechanical double pinch function, the telescopic baffle (ARM) resistance reduction process, within the prescribed period of time the motor stop working automatically, and the intensity is very small, and send out alarm signals;
    • With automatic reset function, after reading the effective card, if the system is not in the passage of time, the system will automatically cancel the pedestrian access;
    • Unified standard external electrical interface, can be connected with a variety of card reader, and through the management of computer remote control and management;
    • The whole system runs smoothly, the noise is small;


Technical Parameters:

    • Power Supply : AC220V + 10% 50HZ
    • Drive motor: DC motor 24V/20W
    • Working: Degree -15 – 60 Degree
    • Relative humidity: relative humidity is less than 90%.
    • Communication interface: RS485 communication,
    • The communication distance is less than 10 meters.
    • Channel width: Flag gate 550mm swing gate single-pole long 300-900MM
    • Traffic speed: 30 person / minute (normally open mode).
    • Gate opening, off time: the Flag gate 0.8 seconds.
